Related
Documentation
Defining CoS Forwarding Classes (CLI Procedure)•
• Defining CoS Forwarding Classes (J-Web Procedure) on page 65
• Configuring CoS Traffic Classification for Ingress Queuing on Oversubscribed Ports on
EX8200 Line Cards (CLI Procedure)
• Example: Configuring CoS on EX Series Switches
Monitoring Interfaces That Have CoS Components
Purpose NOTE: This topic applies only to the J-Web Application package.
J-Web Application package Release 14.1X53-A2 does not support Class of
Service (CoS) on EX4600 switches.
Use the monitoring functionality to display details about the physical and logical interfaces
and the CoS components assigned to them.
Action To monitor interfaces that have CoS components in the J-Web interface, select Monitor
> Class of Service > Interface Association.
To monitor interfaces that have CoS components in the CLI, enter the following command:
show class-of-service interface interface
Meaning Table 108 on page 230 summarizes key output fields for CoS interfaces.
Table 108: Summary of Key CoS Interfaces Output Fields
Additional InformationValuesField
To display names of logical interfaces
configured on this physical interface, click
the plus sign (+).
Name of a physical interface to which CoS
components are assigned.
Interface
Name of the scheduler map associated with
this interface.
Scheduler Map
Number of queues you can configure on the
interface.
Queues Supported
Number of queues currently configured.Queues in Use
Name of a logical interface on the physical
interface to which CoS components are
assigned.
Logical Interface
Copyright © 2017, Juniper Networks, Inc.230
J-Web Application Package User Guide for EX Series Switches, Release 14.1X53-A1
