Table 32: Classifiers Configuration Fields (continued)
Your ActionFunctionField
To add a code point mapping:
1. Click Add.
2. Select the code point.
3. Select a forwarding class from the following
list:
•
expedited-forwarding—Provides low loss,
low delay, low jitter, assured bandwidth,
and end-to-end service. Packets can be
forwarded out of sequence or dropped.
•
best-effort—Provides no special CoS
handling of packets. Typically, RED drop
profile is aggressive and no loss priority is
defined.
•
assured-forwarding—Provides high
assurance for packets within the specified
service profile. Excess packets are
dropped.
•
network-control—Packets can be delayed
but not dropped.
4. Select the loss priority.
To assign a loss priority, select one:
•
high—Packet has a high loss priority.
•
low—Packet has a low loss priority.
Sets the forwarding classes and the packet loss
priorities (PLPs) for specific CoS values and
aliases.
Code Point Mapping
Related
Documentation
Defining CoS Classifiers (CLI Procedure)•
• Example: Configuring CoS on EX Series Switches
• Monitoring CoS Classifiers on page 225
• Understanding CoS Classifiers
Defining CoS Code-Point Aliases (J-Web Procedure)
NOTE: This topic applies only to the J-Web Application package.
J-Web Application package Release 14.1X53-A2 does not support Class of
Service (CoS) on EX4600 switches.
You can use the J-Web interface to define CoS code-point aliases on an EX Series switch.
By defining aliases, you can assign meaningful names to a particular set of bit values and
refer to them when configuring CoS components.
Copyright © 2017, Juniper Networks, Inc.62
J-Web Application Package User Guide for EX Series Switches, Release 14.1X53-A1
