Page #157 background image

Loading...

Page #157 background image

Table 49: Uplink Modules Connector Pinout Information (continued)

Pin NamePin Number

GNDF15

Uplink_Expander_IntrF16

GNDF17

Uplink_P27_LED1F18

GNDF19

POWER (12V)F20

GNDG1

GNDG2

XAUI0_RX1NG3

GNDG4

XAUI0_RX3NG5

GNDG6

XAUI1_RX1NG7

GNDG8

XAUI1_RX3NG9

GNDG10

SRX27NG11

GNDG12

SRX25NG13

GNDG14

GNDG15

GNDG16

Uplink_P25_LED0G17

GNDG18

135Copyright © 2015, Juniper Networks, Inc.

Chapter 9: Pinout Specifications
