Page #158 background imageLoading...
Page #158 background image
Table 49: Uplink Modules Connector Pinout Information (continued)
Pin NamePin Number
POWER (12V)G19
GNDG20
Uplink_PD_LoopbackH1
GNDH2
XAUI0_RX1PH3
GNDH4
XAUI0_RX3PH5
Uplink_P26_ LED2H6
XAUI1_RX1PH7
Uplink_P28_ LED2H8
XAUI1_RX3PH9
GNDH10
SRX27PH11
Uplink_XAUI_MDCH12
SRX25PH13
GNDH14
Serial_RXH15
GNDH16
Uplink_P25_LED1H17
Uplink_P28_LED0H18
POWER (12V)H19
POWER (12V)H20
GNDI1
GNDI2
Copyright © 2015, Juniper Networks, Inc.136
EX4200 Switch Hardware Guide
