2. Press «Enter».
The display for the message type flashes.
3. Use «Up» or «Down» to set the message type.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.3.1 p1
Menu
······························
SP: 0.40bar ¦ SD: −0.2bar
Switching point (SP) and switching differential (SD)
td 120s ¦ Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
DOT1.01 ☐
Output DOT
Warning ☑
Type of message
4. Press «Enter».
5. Press the «Right» arrow.
6. Press «Enter».
The check box assigned to the message type flashes.
7. Press «Up» key.
The message is activated.
8. Press «Enter».
Result The message type is set and activated.
8.8.3.5 Activating the threshold
1. Use «Up» or «Down» to select the
active:
line.
2. Press «Enter».
The check box will flash.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.3.1 p1
Menu
active: ☑
active line with check box
······························
SP: 0.40bar ¦ SD: −0.2bar
Switching point (SP) and switching differential (SD)
td 120s ¦ Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
DOT1.01 ☐
Output DOT
3. Press the «Up» key.
The check box is activated.
4. Press the «Enter» key.
The threshold is selected and activated.
Result In the above example the switching point for
p1
has been set and is active. If the pressure is
reached or exceeded and remains longer than the set time delay
td
, the message is triggered with
the set message type and the set output
DOR
is switched. If the pressure falls below the threshold
SP
+ switching differential
SD
, the message and output are reset. The switching behaviour is inver‐
ted by setting "-" of
Logic
parameter.
The settings for the other measured values are carried out in the same manner.
8 Initial Start-up
8.8 Setting input and output signals
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
129
