KAESER SIGMA CONTROL 2 Service Manual

2. Press «Enter».
The td delay time flashes.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.3.1 p1
Menu
active: ☐
······························
SP: 0.40bar ¦ SD: −0.2bar
Switching point (SP) and switching differential (SD)
td 120s ¦ Logic +
Delay (td) and logic
DOR1.01 ☐
Output DOR
DOT1.01 ☐
Output DOT
3. Use «Up» or «Down» to set the time delay in seconds.
4. Press «Enter».
Result The td delay time has been set.
8.8.3.3 Assign and activate the output
Once the threshold has been reached you can switch a digital output DOR .
1. Use «Up» or «Down» to select the DOR line.
2. Press «Enter».
The DOR output display flashes.
3. Select the output with the «Up» and «Down» keys.
4. Press «Enter».
The setting is applied.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.3.1 p1
Menu
active: ☐
······························
SP: 0.40bar ¦ SD: −0.2bar
Switching point (SP) and switching differential (SD)
td 120s ¦ Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
DOT1.01 ☐
Output DOT
5. Press the «Right» key.
6. Press «Enter».
The check box assigned to the output flashes.
7. Press the «Up» key.
The check box is activated.
8. Press «Enter».
The output is assigned and activated.
ok is displayed.
8.8.3.4 Setting the message type
1. Select the message type line with the «Up» and «Down» keys.
8 Initial Start-up
8.8 Setting input and output signals
128
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E
