Keithley 2010 User Manual

List of Illustrations
2 Basic Measurements
Figure 2-1 Model 2010 front panel .......................................................... 2-3
Figure 2-2 Model 2010 rear panel ........................................................... 2-6
Figure 2-3 Power module ........................................................................ 2-8
Figure 2-4 DC and AC voltage measurements ...................................... 2-17
Figure 2-5 DC and AC current measurements ...................................... 2-22
Figure 2-6 Two- and four-wire resistance measurements ..................... 2-25
Figure 2-7 Offset-compensated ohms measurement ............................. 2-27
Figure 2-8 Frequency and period measurements ................................... 2-29
Figure 2-9 Thermocouple and RTD temperature measurements .......... 2-31
Figure 2-10 Continuity measurements .................................................... 2-36
Figure 2-11 Diode testing ........................................................................ 2-37
3 Measurement Options
Figure 3-1 Moving average and repeating filters .................................... 3-4
Figure 3-2 Front panel triggering without stepping/scanning ................. 3-8
Figure 3-3 Rear panel pinout ................................................................. 3-11
Figure 3-4 Trigger link input pulse specifications (EXT TRIG) ........... 3-12
Figure 3-5 Trigger link output pulse specifications (VMC) .................. 3-12
Figure 3-6 DUT test system .................................................................. 3-13
Figure 3-7 Trigger link connections ...................................................... 3-13
Figure 3-8 Operation model for triggering example ............................. 3-14
Figure 3-9 DIN to BNC trigger cable .................................................... 3-15
Figure 3-10 Buffer locations .................................................................... 3-17
Figure 3-11 Using limits test to sort 100 Ω , 10% resistors ...................... 3-19
Figure 3-12 Front panel triggering with stepping .................................... 3-22
Figure 3-13 Front panel triggering with scanning ................................... 3-23
Figure 3-14 Internal scanning example with reading count option ......... 3-24
Figure 3-15 Internal scanning example with timer and delay options .... 3-27
Figure 3-16 External scanning example with Model 7001 ...................... 3-29
4 Remote Operation
Figure 4-1 RS-232 interface connector ................................................... 4-7
Figure 4-2 IEEE-488 connector ............................................................... 4-8
Figure 4-3 IEEE-488 connections ........................................................... 4-9
Figure 4-4 IEEE-488 connector location ................................................. 4-9
Figure 4-5 Model 2010 status register structure .................................... 4-16

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
