Kinco FD5P AC series servo
Chapter 10 Communication
133
Message meaning
01
——
ID
No.
06——Function code to write a single WORD;
3100——The modbus address of the servo writable object "control word" 60400010, the data length
is a single WORD
00 0F——Write data Hexadecimal 000F
C7 32——Check code
Function code 0x10: write multi-holding register
Request format
Target
station
Function
code
Start address
High Bit
Start address
Low Bit
Quantity
high bit
Quantity low
bit
Force value
Bit number
Force value 1
High bit
Force value 1
Low bit
CRC
1 Byte
10
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
2 Byte
Correct response format:
Target station
Function code
Start address
High Bit
Start address
Low Bit
Quantity high
bit
Quantity low
bit
CRC
1 Byte
10
1 Byte
1 Byte
1 Byte
1 Byte
2 Byte
If the written data is out of range, the address does not exist, and the response to read-
only data operations is wrong, the returned function code is
0x90
Example:Sending message:
01 10 6F 00 00 02 04 4E 82 00 1B ED 56
Message meaning01—ID No.
10——Function code to write multiple WORD
6F 00—The modbus address of the servo writable object "control word" 60400010, the data length is
two WORD
00 02write 2 WORD
04Data length is 4 Byte2 WORD)
4E 82 00 1B—write data hexadecimal 001B4E82decimal 1789570convert
to 100RPM
ED 56——Check code;
10.2.4 Communication troubleshooting measures
When the communication connection between the driver and the Kinco Servo+ cannot be
performed, please refer to Chapter 10.2 to check the communication parameters and wiring of the
driver. When the communication of the drive is easy to drop, read only but not write or only write
but not read, etc., you can troubleshoot through the following aspects
1.
Terminating resistor. When the 485 communication rate is high and the communication
distance is long, the signal will be reflected at the end of the transmission line. Therefore, it is
necessary to connect a 120Ω terminal resistor in parallel at the beginning and end of the
communication network. Since the FD servo drive has its own terminal resistance, it is only
necessary to dial the dial code of the first and last drives to the ON position.
2.
Cable size. The recommended wire diameter of the 485 signal cable is 24AWG, and
shielded twisted pair cables should be used. The shielding layers of the cables should be
grounded together and the grounding resistance should not be greater than . The use of
