Kinco FD5P Series User Manual

Chapter 2 Servo system installation
requirements and notes
Kinco FD5P AC series servo driver
manual
10
Danger!
 Please install it indoor of no rain and direct sunlig
 Please do not use this product in the corrosive environment (Hydrogen sulfide,
Sulfurous acid, Chlorine, Ammonia, Sulfur, Chlorinated gas, Acid, Alkaline, Salt,
etc), flammable gas, combustible and etc.
 Occasion (without Grinding fluid, Oil mist, Iron powder, cutting and etc.)
 Occasion (good ventilation, no Moisture, oil and water, no heat source such as
stove.)
 Occasion which is easy to be checked and cleaned.
 Occasion without vibration.
 Please do not use motor in the closed environment.
 For installation spacing, please follow the requirements of this manual. Using
life of motors depend on working environment.
 Please use screws with washers when installing the motor on the flange,
otherwise the paint on the surface of the motor may be scratched off.
2.2
Servo motor installation
2.2.1 Installation requirements
2.2.2 Environment conditions
Table 2-2 Environment conditions
Environment
Conditions
Working Temperature
-20℃
～
40℃
（
no ice
）
Working humidity
Under 90%RH
（
no condensation
）
Storage temperature
-20℃～70℃（no ice）
Storage humidity
5～95%RH（no condensation）
Vibration
Running: less than 49m/s2(5G)
、
Stopping: less than 24.5m/s2(2.5G)
Collision
Less than 98m/s2
（
10G
）
Protection level
IP65，shaft end: IP54（Shaft end with oil seal: IP54，without oil seal: IP50）
Altitude
Highest altitude: 4000m
，
When the working altitude is above 1000m, the power usage needs to be
reduced by 1.5% for every 100m rise.
