Appendix 1: Braking Resistor Selection
150
Appendix 1: Braking Resistor Selection
The energy generated by the servo motor in the braking state will be fed back to the DC bus of the
drive. When the voltage of the DC bus exceeds the protection range, the drive will report a bus
voltage high fault, and the excess energy needs to be absorbed by an external braking resistor.
When using an external braking resistor, please set the braking resistor resistance value and
braking resistor power correctly. The resistance value of the optional external braking resistor
cannot be lower than the recommended resistance value.
Table 11-1 Recommended specification of braking resistor
Drive model
Power
[W]
Braking resistor resistance [Ω]
reference
model
Braking resistor
power [W]
（
Ref.
）
VDC
（Min.）
Min.
Max.
Ref.
FD415P-□A
FD425P-□A
400W
39
100
75
100
500
380V±5V
750W
Table 11-2 Parameters related to braking resistor
Address
Name
Unit
modbus
address
Command type
Unit
Description
60F70110
Brake resistance
resistance value
Unsigned
16
0x6810
RW
Ω
You can enter the resistance
value and power of the
external brake resistance.
The default value is 0,
indicating that the external
brake resistance power and
temperature detection are
disabled
60F70210
Brake resistance power
Unsigned
16
0x6010
RW
W
60F70310
Brake resistance time
constant
Unsigned
16
0x6020
RW
S
External brake resistance
time constant
S=DEC*256/1000
