Kinco FD5P AC series servo driver manual
Chapter 1 Servo system model and
configuration description
1.5 Servo drive specifications
1PH,200-240VAC±10%
50/60Hz±3HZ (750W 7A) (200W 3A)
No separate logic power supply
Single loop communication type magnetoelectric encoder
Multi-turn communication type magnetoelectric absolute value encoder
Single loop communication type photoelectric encoder
Multi-turn communication type photoelectric absolute value encoder
No built-in braking resistor，If the actual power exceeds the limit power, an
external braking resistor is required (depending on the operating conditions,
mainly used in the occasions of quick start and stop)
Dynamic braking voltage absorption point
External pulse input control
8-segment position can be controlled using DIN signal
Internal parameter of communication setting control
Low-pass filter（Set by internal parameter）
S-curve smooth filter(Set by internal parameters in mode 1)
Pulse+Direction，CCW+CW，A phase+B phase
Maximum input pulse
frequency
Differential transmission mode
：
up too 4MHz
，
Open collector transmission mode：500KHz
Setting range: Gear factor
：
-32768
～
32767
，
Gear divider
：
1
～
32767
，
1/50≤|Gear factor/Gear divider|≤50
Set by internal parameter
0~100.0%（Set by internal parameter）
Position loop sampling
frequency
8-segment position can be controlled using DIN signal
Internal parameter of communication setting control
Low-pass filter（Set by internal parameter）
