1. GENERAL INFORMATION
1-16
MXU 500
Tool Name Tool No.
Illustration
(Note: the special tools may differ
slightly from those shown in the
figure of this manual.)
Driven pulley holder
(Refer to the “DRIVEN PULLEY
DISASSEMBLY/INSPECTION/
ASSEMBLY” section in the chapter
10.
A120E00059
Flywheel puller
(Refer to the “STARTER
CLUTCH REMOVAL/
INSPECTION/
INSTALLATION” section in the
chapter 19.)
A120E00060
Oil filter cartridge wrench
(Refer to the “(Refer to the
“ENGINE OIL” section in the
chapter 3.)
A120E00061
Output shaft bearing nut
wrench
(Refer to the “(Refer to the
“BEARING REPLACEMENT
IN THE RIGHT
CRANKCASE” section in the
chapter 11.)
A120E00066
Lock nut wrench
(Refer to the “CLUTCH
REMOVAL/INSTALLATION”
section in the chapter 10)
A120E00067
(Cont’d)
