2. FRAME COVERS/EXHAUST MUFFLER
2-11
MXU 500
Remove the starter relays and ignition
control module and
Push the lock clip under rear fender by
finger and remove the fuse box.
Remove the five mounting bolts from the
rear fender, then remove the rear fender.
Installation is in the reverse order of
removal.
Ignition Control Module
Starter Relays
Fuse Box
