7. ENGINE REMOVAL/INSTALLATION
7-4
MXU 500
Disconnect the breather hose from cylinder
head cover and remove the mounting nut
from breather housing holder, then remove
the breather housing.
Disconnect the vacuum hose from intake
pipe.
Slide the rubber sleeve back to expose the
starter motor wire nut.
Remove the starter motor cable nut for
disconnect the starter motor cable.
Remove the bolt and then disconnect the
engine ground cable from starter motor.
Remove the A.C.Generator and ignition
pulse generator connectors.
Breather Hose
A.C. Generator Connecto
To Next Page
