13. DRIVE TRAIN
13-41
MXU 500
Remove the oil seal, then remove the
bearing from the cover by using a proper
pipe.
Remove the right ring gear shim.
Remove the ring gear.
Oil Seal Bearing
Ring Gea
r
Shi
m
Ɣ If there is no abnormal condition, the
oil seal or bearing removal is not
necessary
Ɣ The removed oil seal and bearing must
be replaced with new ones.
＊
