13. DRIVE TRAIN
13-47
MXU 500
Install the shim(s) onto the pinion gear shaft,
then install the new bearing onto the pinion
shaft by using a proper pipe.
Install the new bevel pinion gear pilot
bearing into the gear case by using a proper
shaft.
Install the snap ring.
Install the pinion gear assembly by using a
proper pipe.
Install the bearing lock nut by using the
special tool.
Special tool:
Bearing lock nut wrench A120F00020
Bearing Lock Nu
