13. DRIVE TRAIN
13-48
MXU 500
Apply lightweight lithium-soap base grease
to the new oil seal lips.
Install the new oil seal into the gear case by
using a proper pipe.
Install the new water proof plate by using a
proper pipe.
Install the new bearings into the gear case
and cover by using a proper pipe.
Apply lightweight lithium-soap base grease
to the new oil seal lips.
Install the new oil seals into the gear case
and cover by using the special tool.
Special tool:
Oil seal & bearing installer A120E00014
Bearing Bearing
Bearing Bearing
Oil Seal Water Proof Plate
To Next Page
