13. DRIVE TRAIN
13-63
MXU 500
Inspect the universal joint, wear and
damage.
If any defects are found, replace the
bearings, dust seals and universal joint as a
set.
Insert the universal joint to the new bearing
and check the play by turning the universal
joint, as shown.
If excessive play is noted, replace the
bearings, dust seals and universal joint as a
set.
ASSEMBLY
Install the universal joint, new dust seal and
new bearings.
Install the snap rings.
Snap Ring
