13. DRIVE TRAIN
13-64
MXU 500
After reassembling the universal joint,
check the joint movement smoothly. If a
large resistance is felt to movement, tap the
bearing with a plastic mallet lightly.
Fix the boot and spring ring, taking care not
distort the boot.
Boo
t
The dust boot should be fastened with
the spring ring at the groove in the
propeller shaft.
＊
