16. BRAKE SYSTEM
16-44
MXU 500
Install the parking brake case and two bolts.
Tighten the bolts securely.
Apply silicone grease to the new piston seal
and new dust seal, then install them.
Install the piston.
Apply silicone grease to the brake shaft, then
install it.
Apply silicone grease to the dust boot, then
install it.
Parking Brake Case
Dust Boo
To Next Page
