16. BRAKE SYSTEM
16-46
MXU 500
Install the dust boots.
Apply silicone grease to caliper bracket, then
install it.
Install the spring plate.
Install the parking brake caliper (refer to the
“REAR BRAKE/PARKING BRAKE
CALIPER EMOVAL/INSTALLATION
(ON ROAD)” section in this chapter).
Adjust the parking brake (refer to the
“PARKING BRAKE ADJUSTMENT (ON
ROAD)” section in the chapter 3).
Caliper Bracke
To Next Page
