17. BATTERY/CHARGING SYSTEM
17-10
MXU 500
REMOVAL/INSTALLATION
Disconnect the regulator/rectifier connectors.
Remove the two bolts and then remove the
regulator/rectifier.
Installation is in the reverse order of removal.
Regulator/Rectifier Connecto
r
Regulator/Rectifie
r
