17. BATTERY/CHARGING SYSTEM
17-12
MXU 500
Remove the two dowel pins and gasket.
Remove the two pulse coil mount bolts.
Remove the three stator mount bolts,
grommet and the stator from the right
crankcase cover.
INSPECTION
Check the stator and pulse coil for damage.
Dowel Pins
Gaske
