19. STARTER SYSTEM
19-14
MXU 500
Inspect the coil spring for fatigue.
ASSEMBLY
Apply molybdenum disulfide grease to the
coil spring, then install the coil spring.
Pass the rope through the reel and make a
knot above the reel.
Coil Spring
Reel
Knot Rope
Hook
Coil Spring
Ɣ Wear hand and eye protection when
installing the spring, since the spring
may quickly unwind and cause and
injury.
Ɣ Mesh the spring hook with the
housing slit, then wind the housing to
make the diameter of the spring
smaller and the spring will be into the
housing.
＊
