19. STARTER SYSTEM
19-16
MXU 500
Unhook the rope, then turn the reel clockwise
with the rope slowly.
Apply molybdenum disulfide grease to the
washer and friction plate.
Install the pawl spring, friction plate/washer.
Install and tighten the new bolt securely.
Apply Grease Apply Grease
Spring
Bolt/Washer/Plate/Spring
To Next Page
