Chapter 3: Displays
Software Version 3.05
35
The numbers below each channel number is the level of that channel in the cue
being previewed. The levels are shown in different colors according to the code
described below:
?? red = Higher level than the previous cue
?? blue = Lower level than the previous cue
?? white = Non-tracking (or "hard" level), same level as last
cue
?? gray = Tracking (or "soft" level), same level as last cue
Status Bar: The Status Bar is located below the main channel and level
information area. The Status Bar contains the following fields for information:
?? Cue: shows the current preview cue being viewed and edited.
?? Stage Cue: shows the last cue executed on stage.
?? Next Cue: shows the next cue number to be executed when the GO
button is pressed.
?? Mac Pg: shows the number of the macro page (0 - 9) currently being
accessed.
Command Line / Command Line History: Directly below the
Status Bar are the Command Line History and the Command Line. The
Command Line displays the command currently being entered. The Command
Line History shows the last command executed.
Track Mode: The current Track mode (Cue Only, Tracking or Clean Up)
is shown at the far left of the Command Line.
Soft Key Labels: The Soft Key Labels are located directly below the
Command Line. The Soft Key Labels describe the function of each soft key.
The function commands are executed by pressing one of the soft keys, (S1) -
(S10), on the console. The functions of the soft keys change for each display.
