Chapter 3: Displays
Software Version 3.05
39
The numbers below each channel number is the level of each channel. If no
level is listed, the level is zero.
Normal Submaster Status Bar: The Status Bar indicates which
submaster is currently being viewed and edited. The Status Bar contains the
following information fields:
?? Sub: shows the number of current submaster.
?? Name: shows assigned name of current submaster, if any.
?? (Sub Type) shows "Normal" in gray letters as the current submaster
mode. (This information field,
located between the Name and Time fields, does not have a visible label.)
?? Time: shows the time assigned to the submaster Bump button.
?? Prof: shows the profile assigned to the submaster.
?? Bump: shows Bump button mode ("ON", "OFF", "SOLO", or "TOG").
?? Mac Pg: shows number of the macro page (0 - 9) currently being
accessed.
Command Line / Command Line History: Directly below the
Status Bar are the Command Line History and the Command Line. The
Command Line displays the command currently being entered. The Command
Line History shows the last command executed.
Soft Key Labels: The Soft Key Labels are located directly below the
Command Line. The Soft Key Labels describe the function of each soft key.
The function commands are executed by pressing one of the soft keys, (S1) -
(S10), on the console. The functions of the soft keys change for each display.
