4. Parameters
4-64
(4) Position Pulse Clear Mode [P2-16]
Set the operation of position pulse clear mode in position operation mode.
Setting Operation
0
Operate only on the edge where the contact point turns from off to on.
(Do not operate when it is off or on.)
1
Operate immediately at contact point on_ Level. Then, maintain torque when
contact is “High”.
2
Operate immediately at contact point on_ Level. Then, torque is “0” when contact
is “High”.
(5) Output Signal Logic Definition Setting [P2-10]
You can change the output condition of the current output contact point to initial status ON or
initial status OFF.
