7. Product Specifications
7-45
Name
External Dimensions Key Dimensions
Weight
(kg)
L LM LC S T W U
FG22D,FG20G,FG12M 295.7 230.7
114.
2
35 8 10 5
29.23
FG35D,FG30G,FG20M 316.7 251.7
135.
2
34.03
FG44G,FG30M 348.7 283.7
167.
2
41.83
FG44M 370.7 305.7
189.
2
42 8 10 5 47.26
NOTE 1) Use DC power (90V) to operate the brake.
