7. Product Specifications
7-46
Name
External Dimensions
Weight
(kg)
L LM LC LA
FALR5A 103.2(139.6) 78.2(114.6) 49.5 23 0.31(0.66)
FAL01A 120.2(156.6) 95.2(131.6) 66.5 35 0.45(0.80)
FAL015A 140.2 115.2 86.5 35 0.61
NOTE 1) Use DC power (24V) to operate the brake.
NOTE 2) The dimension of ( ) is for brake type motor.
NOTE 3) To connect FAL motor, connect power cable first.
FBL Series | XML-FBL01A, FBL02A, FBL04A
