LSIS XDL-L7SA002X

7. Product Specifications
7-47
Name
External Dimensions
Key
Dimensions
Weight
(kg)
L LM LC S H T W U
FBL01A 107.2(147.2) 77.2(117.2) 48.5(48.3) 14 -0.018 5 5 3 0.56(1.3)
FBL02A 118.2(158.2) 88.2(128.2) 59.5(59.3) 14 -0.018 5 5 3 0.74(1.48)
FBL04A 138.2(178.2) 108.2(148.2) 79.5(79.3) 14 -0.018 5 5 3 1.06(1.8)
NOTE 1) Use DC power (24V) to operate the brake.
NOTE 2) The dimension of ( ) is for brake type motor.
