LSIS XDL-L7SA002X

7. Product Specifications
7-49
Name
External Dimensions
Key Dimensions
Weight(kg)
L LM LC S H T W U
FCL04A,FCL03D 138.7(179.5) 98.7(139.5) 70(69.8) 14 -0.018 5 5 3 1.52(2.32)/1.26(2.06)
FCL06A,FCL05D 156.7(197.5) 116.7(157.5) 88(87.8) 19 -0.021 6 6 3.5 2.14(2.94)/2.12(2.92)
FCL08A,FCL06D 174.7(215.5) 134.7(175.5) 106(105.8) 19 -0.021 6 6 3.5 2.68(3.48)/2.66(3.46)
FCL10A,FCL07D 192.7(233.5) 152.7(193.5) 124(123.8) 19 -0.021 6 6 3.5 3.30(4.10)/2.78(3.58)
NOTE 1) Use DC power (24V) to operate the brake.
NOTE 2) The dimension of ( ) is for brake type motor.
