Lucent Technologies MERLIN LEGEND Release 6.1 User Manual

MERLIN LEGEND Communications System Release 6.1
Feature Reference 555-661-110
Issue 1
August 1998
Features
Page 265Display
Feature Description
Sample Displays
Analog Multiline MLX
Group
Calling
continued
When a group member with an
MLX telephone receives an
outside call for the group, the
type of call is shown on the
display with the label for the line
the call came in on. If caller
identification is available, the
caller’s number is shown on
Page 2 on MLX telephones. For
ISDN calls, Page 1 shows
Called Party Number (if you
have the network service)
instead of the line/trunk label.
Page 1:
No calling group label:
*US&O:$76
&
alling group label:
6$/(6:$76
ISDN calling party ID calls:
2876,'(
Page 2:
No Caller ID present:
7UN
Caller ID present:
7UN
Analog multiline telephone
users see only line information.
Any MLX telephone user can
inspect the number of calls in
queue by pressing the Inspct
button and then pressing a
button programmed with the
calling group’s extension. The
display shows the label
associated with the calling
group and the number of calls.
:$76
No display
*URXS&DOO6$/(6
Hold When an MLX telephone user
or an MLX DLC operator places
a call on hold, a confirmation is
displayed.
When an MLX telephone user
or an MLX DLC operator has a
call on hold for a longer time
than the hold timer value, a
message appears on the
display.
On a QCC only, when a held
call returns to the queue after
the second hold reminder, it is
identified by call type and by the
name and extension of the
operator who put the call on
hold. Line 2 of the QCC display
also shows the caller
information.
No display
No display
No display
&DOORQ+ROG
&DOORQ+ROG
+ROG5HW$+0('[
&DOOHU0$7+,/'([
