110
[1] Left control lever
[2] Right control lever
These are joystick control levers, which can be used for crane, outrigger and travelling
operations.
NOTES
These operations cannot be performed at the same time. It is required to change the operation
mode with the operation mode selector switch (5).
[3] Remote controller power ON/OFF switch.
Use this switch to power ON/OFF the remote controller.
[4] Engine Start/Stop Switch
Use this switch to start/stop the engine.
[5] Operation mode selector switch
Use this switch to select the operation mode from Crane, Front outriggers, Rear outriggers, and
Travel.
[6] Speed selector/Outrigger select switch
In crane and outrigger operations, the operation speed can be changed.
In outrigger operation, the operation can be switched between extension/retraction and extension
stowage.
[7] Load carrying/Fly jib change switch
Only in crane operation, the operation can be switched between boom and fly jib.
NOTES
Operation cannot be changed when a fly jib is not mounted at the front end of the boom.
[8] Accelerator control switch
Use this switch to control the engine speed.
[9] Horn switch
The horn keeps blowing while this switch is pressed.
[10] Emergency stop/Remote controller power OFF switch
Use this switch to bring the engine to an emergency stop. In addition, this switch can be used to turn
off the power to the receiver of the remote controller.
CAUTION
Before restarting the engine, be sure to set the switch to the “OFF” position.
[C1] Cable connection port
Use this port to accommodate an optional cable.
[L1] LED light (front)
Use this light to illuminate an area ahead of the machine.
[L2] LED light (control panel)
Use this light to illuminate the control panel.
