[M1] Left display
Use this display to view various kinds of information.
[M2] Right display
Use this display to view various kinds of information.
[N1] Display operation switch
Use this switch to operate the display.
[R1] Control box
Contains the receiver devices and control devices.
Do not disassemble or modify the control box under any circumstances. Otherwise, an
electric shock, fire, or a malfunction in the controller may result.
[R2] Monitor LED
The control box is equipped with monitor LEDs that show the operation status of the remote
control system.
