4. Operate hook raising or hook lowering to adjust hook
position and secure the hook block to the hook stowage
wire.
NOTES
If the hook block is excessively wound, the over hoist
detector is activated, generating an alarm buzzer. This
allows the winding operation to automatically stop.
5. Change the mode change switch (3) to “Hook
stowage” on the monitor. The hook is wound
automatically; stowing the hook (4).
NOTES
In case of temporary stowage or short distance
self-travelling, you can stow the hook block simply to the
boom head, instead of stowing to the hook stowage wire.
6. Make sure that the crane stowage lamp (1) on the
monitor is lit in yellow.
NOTES
If the crane stowage lamp (1) is not lit in yellow, perform
again the said operation, fully retract and lower the boom,
or slew the boom.
