170
1. Shift the lock lever (1) into the free (F) position.
2. See “OPERATION 2.2 STARTING ENGINE” to start the
engine.
3. Take your foot off the accelerator pedal (6) to allow the
engine to run at idle.
4. Change the mode to Outrigger mode with the mode
selector switch (1) (Travel/Outrigger/Crane) on the
monitor or the left control lever.
5. Make sure that the crane stowage lamp (1) on the
monitor is lit in yellow.
6. Select the Manual mode with the mode selector switch
(3) (Manual/Auto) on the monitor or the left control
lever.
When operating two outrigger switches at the same time, only two on the front side
(outriggers [(1)] and [(4)]) or two on the rear side (outriggers [(2)] and [(3)]) can be
operated at the same time. If two switches on either left or right side are operated at the
same time, two outriggers on one side may be abruptly activated, causing the machine
to overturn.
