364
28. Remove the lever block (23) and the wire (13) that were
mounted to position the pins.
CAUTION
The main boom body, the fly jib body, the lever block (23)
or the wire (13) might be damaged when the main boom is
extended with the lever block (23) mounted.
29. The monitor display changes for the fly jib automatically,
when the fly jib is mounted.
Refer to “Fly jib 5. Handling monitor and moment limiter”
section for details on monitor display.
