8. Applied Functions
LH71A / LH72
8-3. Easy Angle Display Function
• This function counts the angles of arcs by pasting the Digiruler scale on the arcs, and it displays them.
• It displays the angles at the display positions of the axes. (Angles can be displayed for all the axes.)
• Arcs with different radii are supported by setting the radii of the arcs on which the scale is to be pasted.
• Set the measuring unit resolution to the resolution of the Digiruler which is to be connected.
Setting method
1 Press the key to display , and press the key.
2 Press the key.
(The display resolution items are expanded, and angle display is enabled.)
3 Press the key several times to select the desired angle display.
Select 01.00.00 (1 degree), 00.10.00 (10 minutes), 00.01.00 (1 minute), 00.00.10 (10 seconds) or 00.00.01
(1 second), and press the key.
(Values now appear on the display, and the entry of the radius is awaited.)
4 Use the numeric keys to enter the radius, and then press the key.
The value of the minimum radius which can be entered is determined by the measuring unit resolution
and angle display.
If the radius cannot be entered and an error results, it means that the angle display is too low for the
measuring unit resolution. Either set a higher radius or downgrade the angle display resolution.
To Next Page
