(E) 8-1
LH71A / LH72
8-1. Canned Cycle Function (LH71A only)
The following items have the same operating procedure with the canned cycle function.
1 Use the key to make the lamp start flashing, and then press the key to finalize the setting
(lamp lights up).
2 The entered parameters are displayed.
Use the numeric keys to enter the value.
Use the key to cancel.
Use the key to finalize and move to the next option.
Use the key to return to the previous option.
3 The display returns to the value indicator after you are finished entering the parameters. Move to the
position where you want execution to start, and then press key (RUN flashes → RUN lights up).
4 Move so that the number becomes zero, and when the count value for all axes reaches the target value
±3, the NEXT lamp flashes, and you can proceed to the next step.
5 Press the key to display the next set of coordinates, and repeat the same operation.
6 Finally, when all steps have been completed, is displayed (for 2 seconds), and the system exits the
mode.
• To use again, move to the next start position, and execute in the same way.
• To change any parameters, press the key (or key) to display the parameters, and then enter.
• The program cannot be executed unless all the parameters are provided.
• To end machining before completion, press the key. is displayed, and then the incremental
value for that position is displayed. To perform machining again, start from step 1.
• The Canned Cycle Function does not work during the φ (diameter) display.
8. Applied Functions
