Manitowoc 2250 Service And Maintenance Manual

Reference Only
Manitowoc Published 11-06-15, Control # 040-13 1-15
2250 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
Item Description
1 MAX-ER Hydraulic Quick-Couplers
2 MAX-ER Electric Receptacle
3 MAX-ER Load Sensing Storage Receptacle
4 Auxiliary Valves Junction Box
5 Not Used
6 Jacking Remote Control Receptacle
7 Not Used
8 Setup Remote Control
9 Jacking Remote Control
10 Engine Air Cleaner (Past production and Tier 3 shown)
11 Remote Control Storage Compartment (under panel)
12 Drum Drive Gear Case
13 Battery Compartment
14 Remote Start Junction Box
15 Engine Start Switch
16 Engine Run-Stop Switch
17 Hydraulic Disconnect Switch
18 Engine Speed Switch
19 Flow Control Valve (to rotating bed auxiliary valves)
20 Rotating Bed Auxiliary Valves
21 Relief Valve (rotating bed valve assembly)
22 Auxiliary System Disable Valve
23 Auxiliary System Disable Manual Override
FIGURE 1-6 continued

Manitowoc 2250 Specifications

General

Brand	Manitowoc
Model	2250
Category	Construction Equipment
Language	English
