Manitowoc Grove GMK4100L-1 User Manual

Operating elements for driving
3.2 Short description of the operating elements
Operating manual 3 302 690 en 3 - 63
GMK4100L-1
23.11.2017
Steering locking status display
The current status is shown using different
symbols:
Current wheel position display
The current status is shown using different
symbols:
1 Green – locked
2Red – unlocked
3 Yellow – intermediate position
4 Error
1 Straight ahead
2 Driving around corners
3 Crab travel mode
