Additional pages GMK4100L-1 3 302 710 en 25
16.01.2018
Normal steering When driving a rigged truck crane, always use the separate steering;
à p. 22.
Switching to normal steering mode
Use buttons (1) and (2) to turn the wheels to
the
Straight ahead position – the current
wheel position is displayed.
Select and confirm the symbol (3) –
symbol (4) is displayed.
If the error symbol is displayed, contact
Manitowoc Crane Care.
Steering in normal steering mode
The symbol (2) is displayed.
Steer the 1st and 2nd axle lines with the button (1).
The wheels of the 4th axle line are turned correspondingly for driving
around the corner.
To turn to the left: Press button (1) to the left.
To turn to the right:
Press button (1) to the right.
