16.01.2018
24 3 302 710 en Additional pages GMK4100L-1
Steering with separate steering – manual
The symbol (3) is displayed.
• Steer the 1st and 2nd axle lines with the button (1).
• Steer the 3rd and 4th axle lines with the button (2).
The axle lines are steered as long as you keep the button pressed or until an
end position is reached.
(A) – For driving around corners
• Steer the 3rd and 4th axle lines opposite to
the 1st and 2nd axle lines.
(B) – For crab travel mode
• Steer the 3rd and 4th axle lines in the same
direction as the 1st and 2nd axle lines.
– To turn to the left:
• Press buttons (1), (2) to the left.
– To turn to the right:
• Press buttons (1), (2) to the right.
