Operating elements for crane operation
9.2 Short description of the operating elements
9 - 148 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
Reading lamp
Windscreen
wiper/washing
system
Windscreen wiper on/off
Roof window wiper on/off
Windscreen washing system
1On
2Off
– Off: Middle position
– Interval: Push up – wiper goes to end position
– Continuous operation: Push down
– Off: Middle position
– Interval: Push up – wiper goes to end position
– Continuous operation: Push down
– Windscreen: Push down
– Skylight: Push up
No additional wiping function is performed
