Rigging work
12.9 Rigging/unrigging the counterweight
Operating manual 3 302 690 en 12 - 79
GMK4100L-1
23.11.2017
5. Enter the current rigging mode with the currently rigged counterweight
combination;
à p. 11 - 32.
6. Depending on the driving mode, lift the necessary counterweight
sections
– on to the
front counterweight platform;
à Slinging points on the counterweight sections, p. 12 - 74,
à Driving modes, p. 6 - 1.
–from the
rear counterweight platform;
à Slinging points on the counterweight sections, p. 12 - 74,
à Driving modes, p. 6 - 1.
– If the base plate is being transported on the
rear counterweight
platform, lock the counterweight platform;
à Locking, p. 12 - 96.
