Manitowoc Grove GMK4100L-1

Malfunctions during crane operation
14.8 Fuses in the crane cab
14 - 76 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
Designation Amperage (A) Function
F4/1 3 Control unit UE IOL 30, CCM 10, UE SCM
F4/2 3 Reserve
F4/3 3 CraneSTAR system
F4/4 10 Radio
1)
F4/5 – Unassigned
F4/6 – Unassigned
F4/7 – Unassigned
F4/8 – Unassigned
Designation Amperage (A) Function
F5/1 5
Control unit 15 SCM, CCM 10
Control unit UE IOL 30, IOS 22
F5/2 5 Control unit 15 UE IOS 20 and 21
F5/3 3
CCS display
F5/4 3 CAN bus system
F5/5 5 Control lever supply
F5/6 – Unassigned
F5/7 – Unassigned
F5/8 5 Switch lighting
1)
Additional equipment
