Manitowoc Grove GMK4100L-1

Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating manual 3 302 690 en 14 - 77
GMK4100L-1
23.11.2017
Designation Amperage (A) Function
F6/1 5 Windscreen washing system
F6/2 15 Sockets 12 V
F6/3 10 Crane cab spotlight
F6/4 15 Main boom spotlight
F6/5 5 House Lock
F6/6 3 CraneSTAR system
F6/7 3 Radio control
F6/8 5 Camera system
Designation Amperage (A) Function
F7/1 3 Rotating beacons
F7/2 5 Diagnostic connection
F7/3 3 Heating system
F7/4 3 Extendable step for crane cab
F7/5 5 Hoist camera tripod
F7/6 – Unassigned
F7/7 – Unassigned
F7/8 – Unassigned
Designation Amperage (A) Function
F8/1 5 Crane control power supply
F8/2 3 Crane control power supply
F8/3 3 Crane control power supply
F8/4 3 Crane control power supply
F8/5 – Unassigned
F8/6 – Unassigned
F8/7 – Unassigned
F8/8 3 Crane control power supply
