15 MULTIVOLUME INSERT OPTION
The MultiVolume Insert option provides analysis of samples using smaller-sized sample chambers.
Wear latex gloves when handling inserts and sample cups. Oils from skin may con-
taminate the surface and affect analysis results. See Handling System Components
on page11 - 5.
Equipment
Description
AccuPyc 1 cm
3
Includes a 0.1 cm
3
insert / sample cup combination.
AccuPyc 10 cm
3
Includes 1 and 3.5 cm
3
inserts with corresponding sample cups and
appropriate calibration standards. Fritted filter lids are included for both
inserts.
AccuPyc 100 cm
3
Includes 10 and 35 cm
3
inserts with corresponding sample cups and
appropriate calibration standards. A fritted filter lid, which prevents the
escape of sample particles under rapid gas flow, is included for the 10
cm
3
insert.
AccuPyc 2000 cm
3
Includes 650 and 1300 cm
3
cups, supporting inserts and calibration
standards. A tool is also included to allow removal of the supporting
inserts.
An insert changes the size of the sample chamber and requires its own sample cup. All inserts are
shipped with appropriate cups, with the exception of the 0.1 cm
3
insert for the 1 cm
3
unit. Because of
its size, the sample cup for the 0.1 cm
3
insert is built-in. The appearance of the inserts and cups
varies.
n The fritted filter caps for the 1 cm
3
and 3.5 cm
3
inserts fit on top of the insert.
n The cap for the 10 cm
3
insert (shown in image) fits on the sample cup.
15 MultiVolume Insert Option
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev A) — Jan 2021
15 - 1
