106 SyncServer 600 Series User’s Guide 098-00720-000 Revision D1 – February, 2018
Chapter 4
Navigation Windows
Reflector capability is only available when the existing Security License option is
installed. PTP is only available with the appropriate PTP license option.
The reflector does not support symmetric security keys or Autokey.
The timing service will only support one IP address. When using IPv6, there could
be multiple IPv6 addresses associated with the Ethernet port. The IPv6 address can
be selected by the user or automatically selected by the system in the following
order.
1. Configured static IPv6
2. First available global address - DHCP or autoconfig
3. Link-local
The unit will not respond to IPv4 NTP packets if the reflector is enabled for IPv6.
The unit will not respond to IPv6 NTP packets if the reflector is enabled for IPv4.
Profile When appropriate, this column is used to further refine the categorization
of the timing service. A good example of this in 2.1 release is a PTP
master (top-level service), which always operates with a specific PTP
profile.
Configure For a timing service that has additional configuration parameters, this
selection brings up a form where all remaining parameters can set as
desired.
Selecting OK on the configure form maintains this configuration as long as
the associated timing service row is being worked on. When (if) the Save
selection in that row is executed, then the configuration becomes part of
that service.
Save Use this to save the timing service configured on this row.
This also saves the settings (if any) that are associated with Configure for
this same row.
Delete Remove the specific timing service configuration associated with this row.
If the row being deleted is currently mapped for use on a physical port, this
action will not be allowed. If you really want to do it, first unmap it on the
Network Timing'NTP/PTP Mapping form.
Table 4-8. NTP / PTP Services Configuration Parameters (Continued)
Parameter / Column Description
